Product information "Levina 5387 series 5387XSC125P30-13"
The Pros
- Total lock for simultaneously locking the wheel and swivel housing
- Two stainless ball races in the swivel head for easy steering
- Extremely high shock absorbing
- Stainless steel version
- Equipped with Maxtech Conductive (XSC) wheel treads
- TÜV Süd certified to EN 12530 and a dynamic load of 100kg
Read more...
Description
The Tente Levina castor is suited for a wide range of equipment used in various hospital environments. MSP currently offers the Levina 5387 series in a diameter of Ø100mm and Ø125mm in the XSC Maxtech Conductive wheel tread. This is the braked version of the Levina with total lock functionality. Optionally the 5387 series is also available with an extended brake pedal for easier application of the brakes.
Please browse the brochure of the Levina in the downloads sections for further details and information. Should you require a different fitting method, diameter or wheel tread, please contact us for the possibilities.
Select the desired wheel tread, diameter and bolt hole size above and you will be able to download the appropriate datasheet from the downloads section as well.
A complete overview of the specifications of the selected version can be found under the tab "Specifications".
MSP, the smarter alternative. Always!
Specifications
| Product number: | WHTEN030025 |
|---|---|
| Manufacturer: | Tente |
| Replaces OEM Product Number: | 5387XSC125P30-13 |
| EAN/GTIN: | 4031582359473 |
| Weight: | 0.65 kg |
| Certification: | EN 12530 |
| Field of Application: | Emergency Room, Operating Room, Radiology Room, Restaurant Area |
| Hardness of tread: | D 40 Shore |
| Offset: | 38mm |
| Static Load: | 200kg |
| Suited for Equipment: | Catering Trolleys, Console PC, Instrument Carts, Medication Carts, Mobile X-Ray Unit, Surgical Carts, Tray Carts, Trolley Tables, Ultrasound Carts |
| Swivel radius: | 101mm |
| Tyre Width: | 32mm |
| Tente Model Series: | Levina |
| Wheel Diameter: | 125mm |
| Mounting method: | Bolt Hole Ø13mm |
| Wheel tread: | XSC |
| Housing Color: | Window Grey |
| Electrical Conductivity: | Yes (XSC) |
| Brake function: | Braked |
| Build Height: | 161mm |
| Stainless Steel Bearings: | Yes |
| Dynamic Load: | 100kg |
| Type of spare part: | Castor |
